| Description: |
Boom Type 3-Section
Maximum Lift Height 34'3"
Maximum Reach 23'3"
ENGINE
Engine Manufacturer John Deere
Engine Model 4045T
Horsepower 99
Gross Horsepower N/A
Cylinders 4
Aspiration Type Turbocharged
Cooling (Air/Liquid) Liquid
Displacement (cu. in.) N/A
Rated RPM 2,500
Torque @ RPM N/A
TRANSMISSION
Transmission Powershift
Number of Speeds 3F/3R
Speed (F/R) 1st Gear N/A
Speed (F/R) 2nd Gear N/A
Speed (F/R) 3rd Gear 20.2F/- mph
Speed (F/R) 4th Gear N/A
Maximum Travel Speed 20.2 mph
Drive System 4WD
HYDRAULICS
Hydraulic Pump Type Gear
Maximum System Pressure 3,000 psi
AXLES & TIRES
Axle Type Planetary
Drive Tires Size 15.00 X 19.5 12-PR
Steer Tire Size 15.00 X 19.5 12-PR
BRAKES
Service Brakes Wet Disc
Parking Brake Hydraulic
STEERING
Steering 2W/4W/Crab
PERFORMANCE
Base Capacity 6,000 lbs
Max Fork Height Rated Capacity 4,000 lbs
Capacity @ Max FWD Reach 900 lbs
Max Capy @ Max Rch w/Outrigger N/A
Load Center N/A
Maximum Drawbar Pull N/A
WEIGHTS & DIMENSIONS
Operating Weight 15,100 lbs
Overall Length 192 in
Overall Width 94 in
Cab Width N/A
Overall Height 94 in
Front Overhang N/A
Fork Size (W x L) 1.5 X 5 X 60 in
Outside Turn Radius 150 in
Maximum Boom Angle 70 deg
Minimum Boom Angle N/A
Boom Reach Below Grade 24 in
Wheelbase 110 in
Tread (Front/Rear) N/A
Ground Clearance 14 in
FLUID CAPACITIES
Fuel Tank 29 gal
Cooling System Capacity N/A
Hydraulic System Reservoir 35 gal
|
