Grout Pumps, Grout Mixer, Hand Grouting Pumps, Mud Pumps :
3/8 Minus Concrete Pumps
We offer best pricing for new and used Putzmeister, Multiquip, Mayco, Olin, Schwing, Chem Grout and most concrete pump manufacturers.
We offer complete parts and repair services.
Discount Sale Grout Mixer Mud Hog !
|
|
|
C30HDG
Call Dick (503) 283-2105
Zenith ZPP416 68-HP gasoline engine
The C30HDG grout & concrete pump offers uncompromising engine performance with excellent fuel efficiency in a quiet, smooth pumping package.
|
|
Pumps up to 25 cubic yards (19 cubic meters) per hour
- Maximum aggregate size of 1/2-inch minus (12 mm)
68-hp (51kW) fuel-injected Zenith gasoline engine ensures quiet, efficient performance
- Standard 2-function 125-foot (37.5 meters) hardwired remote. Multi-function radio remote with full volume control and 1,000-foot (300 meters) operating range (Optional).
- Fully-enlclosed piston lubrication box and central lubrication grease station
- Standard equipment includes a 3-inch (76 mm) x 90 degree pipe elbow, 3 x 2 x 28-inch reducer, and two 3-inch couplings (all raised ends)
- Excellent choice for small-aggregate concrete pumping, masonry grout, shotcrete, pressure grouting, and more
|
Engine Specifications
| Engine Make/Model |
Zenith ZPP 416 |
| Start Method |
Electric |
| Engine Power |
68 HP |
51 kW |
| Fuel Type |
Gasoline |
|
Unit Specifications
| Pump Type |
Reciprocating piston |
| Hopper Capacity |
6 ft? |
0.17 m? |
| Material Hose Diameter |
3 in |
76 mm |
|
|
|
Pumping Specifications
Volume Output
per Hour* |
25 yd? |
19 m? |
| Vertical Pumping Height* |
150 ft |
46 m |
| Horizontal Pumping Distance* |
500 ft |
152 m |
| Concrete Piston Face Pressure |
500 |
| Max. Aggregate Size |
0.5 in |
12 mm |
| * These figures will vary due to concrete mix design, line size, and job site conditions. |
Dimensions & Weights
| Overall Length |
144 in |
3658 mm |
| Overall Width |
59 in |
1499 mm |
| Overall Height |
65 in |
1651 mm |
| Operating Weight |
2920 lb |
1325 kg |
| All weights are approximate. Exact weight is dependent upon power source used. |
|
OLIN'S "BALL VALVE" models offer proven performance and reliability for placing grout and pumpable concrete mixes containing aggregate up to 1/2" in diameter.
Easy to operate, simple and inexpensive to maintain
Quality hydraulic pumps, REXROTH
Quality engines, DEUTZ
Simple and RELIABLE HYDRAULIC SYSTEMS
Dependable electric cycling |
|
|
|
|
|
| |
Schwing SP88
|
|
